Don't know which SCADA company to choose? Let Progea make it easy!

What’s new in Movicon 11.2





SCADA - HMI Software - Web Client

Software Products for Automation

The Progea software products  are based on the most modern and innovative technologies to guarantee the highest productivity and the fastest return on your investments.  Our products are installed worldwide to supervise and control any automation field, especially for the following sectors:

  • Food & Beverage
  • Automotive
  • Manufacturing
  • Pharmaceutical
  • Energy, Oil & Gas
  • Waste & Wastewater
  • Building Automation

More than 40.000 installations worldwide clearly demonstrate the quality and reliability of our products which can be deployed in any field of automation, such as industrial automation, building automation and process control.

The product range is:

  • MES and Plant Intelligenge software suite
  • SCADA (Supervisory, Control and Data Acquisiton) Software Platform
  • HMI (Human Machine Interface) software
  • SoftLogic IEC 61131 software

All the  software solutions have been designed by Progea to guarantee you:

      • Easy-to- useness
      • Openness
      • Standards
      • Flexibility
      • Re-usability
      • Connectivity
      • Security
      • Reliability

Progea's software products mean quality and standards. Movicon is certified as "Designed for Windows Vista" by Microsoft, and its OPC technology has been "Tested & Compliant" by the  OPC Foundation.

Movicon 11 - The innovative XML-based Scada/HMI

logo_120_Movicon11

Movicon™ 11 is the software standard for all those operating in industrial automation, in remote control and building automation, a universal and flexible Scada/HMI platform adaptable and deployable anywhere with maximum scalability and independence from hardware devices.
The supreme openness and flexibility of the Movicon™ architecture makes it the perfect Scada/HMI supervision solution appliable to any sector in the world of automation The new features of Movicon™ 11.1 get your supervision closer to reality.

Movicon 11 PDF

Download

Tutorial:

Getting Started with Movicon™11

Movicon 11 BA Edition, the Scada/HMI for Building Automation

Progea has designed a Movicon 11 special product version especially for the Building Automation sector, Facilities and Domotics.

Integrated Building Management.
The ever-increasing demand for Building Automation and domotics prompted Progea to create a special poduct line for this sector.
The Movicon™ BA software is more capable of making your building supervision the most powerful, open and scalable than any other software around.

Movicon™ BA is Progea’s supervision solution for intelligent buildings. Progea is a major leading expert company in supervision and control software systems (Scada/HMI). Movicon™ BA offers all the great advantages of ‘Open’ software for integration and visualization of automation systems for modern buildings, whether residential, industrial, services or big communities. Movicon™BA provides all the advantages of modern software with very flexible solutions. Great experience matured through years of success, has allowed Progea to deliver solutions to all those who demand an integrated system using an all-in-one, powerful, open, visualization and control software.

Movicon 11 BA PDF

HMI Technology for Windows CE

Movicon CE is a runtime engine for Windows CE that offers HMI solutions powerful and open. Just one development platform and your Movicon XML projects can be run on Win32, Win64 or WinCE indifferently.

Movicon™ CE is the most powerful HMI platform avialable for  Windows™ CE today, wholly capable of satifisying your every need in visualization and control in a compact environment without forgoing the potentiality of the Scada system.


Movicon™ CE is a runtime engine with runs the same Movicon™ 11 XML projects.
Your projects can therefore be run on your HMI device, in operator terminals, PDA, Palmtop PCs, Smartphones, mobile and Wireless Systems (Pocket PC and HPC2000), autonomously and independently, without needing client stations and other applications.  In fact, your WinCE device can be the Server or Web Server itself, to other client stations.   Movicon™ CE, installed on your WinCE device will therefore run projects created by your Movicon™11 platform: one project only, the same file, run on different platforms all made possible by the project’s XML structure.  This means much greater management simplicity, significant reductions in maintenance costs and maximum information transparency.

Movicon™ CE

MovTracer. Integrates your plant with your business

Movtracer_Logo_3

MovTracer is the MES solution for collecting, aggregating and recording vital manufacturing company information in your  preferred database format.  Production data acquisition in realtime and monitoring main performances
(KPI,OEE) allow you to make roductivity
improvements, reduce loses and increase profits.

WEB-BASED ARCHITECTURE

Movicon Web Client Information accessible  from anywhere throughout the web

Revealing factory information wherever and in real time is a strategical must-have that any manufacturing company is well aware of.  This is the reason why Progea has especially designed Movicon™ Web Client, the innovative software solution based on the most modern Thin Client Java technologies for sharing real-time data across internet or intranet network architectures.

Thanks to the Movicon™11 and Movicon™ Web Client technologies you can visualize and control any Movicon™ HMI or Scada supervision station using a simple browser on the client, saving you major costs in management, maintenance and licensing, while increasing your company productivity at the same time.

Each Movicon™ project, run on Win64, Win32 or WinCE, is equipped
with a powerful Web Client solution.

Being able to get realtime factory information no matter where and when is a strategical must-have that any serious manufacturing company is well aware of.
This is why Progea has especially designed Movicon™ Web Client, the innovative
software solution based on the most modern Thin Client Java technologies for
sharing real-time data across internet or intranet network architectures. Thanks
to the Movicon™11 and Movicon™ Web Client technologies you can visualize
and control any Movicon™ HMI or Scada supervision station using a simple browser
on the client, saving you major costs in management, maintenance and ownership
licensing, while increasing your company productivity at the same time.

Truly Web-based Architecture. Movicon™ Web Client uses the Thin Client model, thanks to which the whole application can reside and be processed on the server. By centralizing information, system management and maintenance
will become simpler and low-costing. The Client displays graphics processed on the
server through any Internet browser, by interacting and adapting the graphics to
local resolution requirements. The Client is updated on event, upon each change
only. The most advanced technologies (Java, XML, Web Services) and exception
technology guarantee performances with truly innovative architecture.

Thin Client Model Innovation. Movicon™ Web Client exploits the java technology and Web Service communication for visualizing and controlling your automated plant from
any client station in local or geographic network. The Web Client solution designed
by Progea does not need extra installation or configuration on the server side.
Multiuserness, bidirectionality and security are all guaranteed at the same time
without requiring complicated configuring. The Movicon™ Web client technology
exploits the Windows™ Web Server (IIS) for default, connecting your entire plant
through the web with just a few clicks. Furthermore, the Movicon™ Web Client
access, consenting simple HMI stations to become Web Servers. Movicon™ Web
Client is very thin (about 300 Kb) and can be run in any browser with any operating
system, thanks to the java multiplatform support. By exploiting HTML pages created
automatically by Movicon™, the Web Client permits visualization and control of
the production process from any part of the world, using communication concepts
based on TCP-IP, and optimized for public networks with low frequency band widths,
with option to encypt, rendering your application well and truly "web enabled".
The innovative advantages of Movicon™ Web Client permit you to monitor and
optimize production processes at a low cost. Whatever you manufacture, you can
visualize and control automation systems or machines and beat ownership license,
development and system maintenance costs. Data is centralized in distributed
architectures only where needed: on the Server. Clients display and interact with
the Movicon™ project to which they are connected, without needing to pay
any additional license and development costs, thus simplifying maintenance.
Modifications executed on the Server will immediately be updated to all Clients.

Unmatched Potentiality throughout the Web.
Client users, without installing and processing any thing on Client stations, are fully aided with the potentiality that only the Movicon™ Web Client is capable of offering.  The graphical representations of screens are shown in their ‘true colors’ and graphics are automatically adapted to the client’s graphic resolutions or to the size of the browser window.   On the Client side you can interact with and activate commands and manage events of VBA code inserted in symbols.   All information from Historical Logs, Trends can be obtained and data tables displayed with filter and order by support.   The Scheduler and IP Camera viewer objects are supported along with their interactivities.   The Movicon™ Web Client potentialities are incredibly outstanding, powerful, extremely simple and automatic, truly making the automation-over-the web concept a real ‘live wire’.



Web Client features
Movicon™ Web Client offers the possibility to access factory data using Internet/Intranet architectures.  The advantages you get from using the Movicon™ Web Client are:

  • Accessing and displaying projects over the web using any browser with any operating system, made possible by Java technology support, and in the J2ME version for supporting the JavaPhones technology.  Creating Web pages on the server is completely automatic with one click only.
  • Project screen navigation as predefined on server, possible restrictions may occur navigating on the Web side.
  • No need to install or configure extra on Client or Server.
  • Enhanced performances, transparent support to the project functionalities and commands using a normal browser.
  • Secure data management.
  • Notification on exception only
  • Communications based on Web Services.
  • Entirely Java-based technology.
  • Support to Applet J2SE and Midlet J2ME.
  • Multiplatform support on Client side (Linux, Windows™, Palm, Symbian, Javaphones).
  • Support to Windows Vista/XP or Windows CE on Server side
  • Access to Server by mobile phone acting as plant system client.
  • Complete access from Web side to historicals recorded by Server
  • Support to powerful functions such as schedulers or IP camera viewers.

Web Client becomes mobile!
Movicon™ Web Client is the only Scada/HMI in the world that allows Web Clients to log on with mobile phone devices, all made possible with the Web client Midlet, to consent access to the supervisor using normal mobile phones with Java J2ME 2.0 support.  Users can now receive event notifications over the phone, connect immediately to the plant system (GPRS/UMTS) to get information on tags, alarms, historicals and even display and interact with screens wherever they happen to be.



Web Client Demo Online.

webcli_demo

Clic here to access as Web Client to a Movicon Demo project.

WARNING: allowed only 2 users connected simultaneously. In case of unavailability, try again later..



Progea

Progea is a company focused on Automation and Process Control. The company's Research Lab develops software products and components for industrial Automation, Building Automation and for Remote Control systems.
Progea started in 1990 in response to the strong demands for software and services in the automation field. Experience gained through the years by collaborating with leading companies has helped formed the foundations on which the Movicon Scada platform is based.
Progea is a company in continuous growth and is constantly investing in research and quality for its software product due to its important capacity to analysis and build its knowledge on integrator needs and requirements deriving from the automation market.

Progea is quality system management UNI EN ISO 9001:2000 standard certified.
Progea's constant growth in success has branched out to new offices in Legnano (Milan) and abroad in Germany, Progea Deutschland GmbH, and recently in Switzerland, making the Company a protagonist among the international producers in automation software platforms with an annual turnover  increase of over 20%.

Product link

 Thinking to the future.

Progea is an international company with foresight in future industrial automation and Process Control software. The latest Microsoft technologies are incorporated into Movicon Scada software package and SoftLogic system, to increase your productivity and improve reliability.
Progea provides top quality technical services and assistance worldwide. Progea is represented around the world by a large number of highly qualified partners which are always on-hand to give assistance and support.
Our mission is to develop and produce software products (Scada, SoftLogic, Web-based software) based on open and standard architectures, which are both easy-to-use and scalable, to give customer satisfaction and success with their automation and Process Control applications.
Progea produces and distributes Movicon, a powerful Scada/HMI software for Automation and Building Automation, to visualize, monitor, control and remote control their plant. Movicon is the solution whcih comes complete for managing Scada functions and incorporating Web Client functions for Internet/Intranet architectures.
Progea distributes many other products for industrial automation, such as software components for remote control, tools and hardware accessories for industrial communication.
Progea is your partner when you need to communicate with your automation process and monitor, supervise, control and acquire data.

STRONG POINTS

Scalability.
Movicon™11 is an all in one software
platform from Windows™ CE to
Windows™ Vista. Only one platform is
all you'll ever need in your company for
micro applications in HMI terminals or/
and medium and big applications for
manufacturing process plant systems.

Openness.
Movicon™11 is completely based on
XML. Projects are simple XML files, which
can be opened and edited with any
other Editor. Fully open to integration
and customization with the world of
Windows™ applications. Projects can
be grouped in hierarchical structures,
distributed and shared.

Security.
Movicon™11 guarantees the top data
security. Projects, though based on XML,
can be encrypted with 128 bit coding
algorithms. The platform is FDA 21 CFR
Part 11 compliant for creating FDA ready
applications with extreme ease. The User
Password manager guarantees safe access
by level and/or area. The built-in Visual
Source Safe guarantees safeguarded work
at all times.

Standards.
Movicon™11 is completely based on
standard technologies to ensure that your
investments are safeguarded. The XML,
ODBC, OPC, VBA, SOAP, Web Services,
TCP-IP and SQL technologies are all
built-in to guarantee easy data access and
transparency.
Performances.
Movicon™11 enhances performances
by renewing its "exception-based"
technology concept and Graphics engine
now based on SVG (Scalable Vectorial
Graphics).

Connectivity.
Movicon™11 has implemented a new
generation of communication drivers
with automatic Tag importer, remote
connectivity via modem, multi-station
concept for point-to-point protocols,
bridging concept for teleservices in
PLCs, immediate cable testing. These
drivers guarantee full configurability
and possibility to communicate on event
with custom VBA logic. Not only do you
get a free and included driver library,Movicon™11 also provides you with total
connectivity via OPC DA, using both the
OPC DA and OPC XML DA technologies as
Client and Server.

Very Efficient Networking.
Movicon™11 has a sophisticated
Networking technology, capable of
giving you network connectivity between
any HMI or Scada station in an instant.
Any Movicon application type can be a
networking server for any other station,
(WinCE or WinXP), and client stations are
connectable within a few clicks. Efficiency
and performances are guaranteed with
"event-driven" architecture and emergent
multiplatform technologies such as
SOAP (Simple Object Access Protocol)
and SOA (Service Oriented Application).
Movicon™ projects can be Server and
Client indifferently. Client projects can be
distributed and run locally on the client
while residing on the central server. The
Movicon™ networking can be applied
to any enterprise network integration
according to network administrator needs:
TCP-IP as well as UDP and HTTP protocols
are also supported. The networking
feature automatically manages remote
connections via RAS. Movicon™11
integrates the Web Services technology,
consenting information distribution
support to public networks (internet).

Web-enabled Architecture.
Movicon™11 has renewed Web
Client technology. The innovative
architecture, based on JAVA (integrating
perfectly with XML, SVG, Web Services
technologies), consents server access
using internet browsers in any platform
(Windows™, Linux, Palm, PocketPC and
Javaphones thanks to J2ME). Multiuser,
bidirectionality, performances and security
are guaranteed for cost and maintenance
effectiveness. Servers can be both
Windows™ Vista/XP and Windows™ CE.

SoftLogic IEC 61131-3.
Movicon™11 integrates the Logicon
SoftPLC to guarantee an all-rolled-intoone
programming environment whether
on the SCADA/HMI side or SoftPLC side.
This means that just the one Tag DB
synchronized using just the one editor,
saving development time while enhancing
potentiality significantly. The SoftLogic has
a powerful programming environment
with the 5 IEC1131 languages, powerful
debug and documentation functions, a
deterministic and a real-time runtime, for
both Win32 and WinCE.

I/O Divers Included with the package:

  • Siemens S7 PPI
  • Siemens S7 MPI
  • Siemens S7 Ethernet TCP
  • VIPA direct MPI
  • VIPA  Ethernet
  • Rockwell EtherNetIP
  • Rockwell DF1
  • Mitsubishi FX2, FX3 Eth
  • Mitsubishi Q-series
  • Omron FinsEthernet
  • Omron HostLink
  • Saia (multiport Interface)
  • Panasonic Matsushita FP Serial
  • Panasonic Matsushita FP Ethernet
  • Schneider Unitelway
  • Modbus RTU
  • Modbus TCP-IP
  • Profibus DP
  • CAN Open
  • Interbus
  • Hilscher NetLink, CIF (Profibus, CAN, ecc)
  • Applicom (Profibus, ecc)
  • Twincat Beckhoff
  • IBH
  • Lenze
  • OPC Client



Content on this page requires a newer version of Adobe Flash Player.

Get Adobe Flash player

Other Products

Software Tools and modules
Progea produces software modules which are very useful in Movicon applications. Those modules can be easily integrated with Movicon and with other Progea software products. Each software modiule has been described below. You will find a description on each software module by clicking the corresponding hyperlink on the left.

Alarm Dispatcher.
This is a software application to manage Alarm and Message dispatching via SMS, E-mail, Voice, Fax and Messenger. By configuring its numerous properties, this application can be deployed as an Alarm Dispatcher in any other application needing to send messages. This application has "Text-to-speech" engine integrated and supports the phone key tone management for acknowledging commands in the supervisor.

SPC Chart.
This module is an ActiveX object designed to represent statistical curves in charts of any datalogger. This object can be used with any platform type.

Hotel Automation.
This is a set of graphic templates which manage "Hotel Room Access" in automatic (Check-IN and Check-OUT). They also manage Hotel Room technical information (Temperature, presence, alarms, etc.). This automation has been expecially designed to communicate on EIB bus and can be developed in next-to-no-time and used in any Hotel application.

Biometric Fingerprint Scanner
INS can supply you with  the FKey biometric finger scanner from TOCA on request.  This is a plugin device which can be plugged into any USB port (Win32), and is sold together with a software module to allow Movicon users automatic system access using their fingerprint as id for logging on to Movicon X projects.  This also comes with an example project.

SIMATIC© S7 Interfaces.
INS can provide you with hardware devices  on request to communicate directly with Simatic S7 PLCs.
Movicon includes several I/O drivers to support any Siemens device and any other communication card. INS also supplies very cost efficient  R232-MIP/PPI Adapters and high performing LAN-MPI Adapters.

Industrial GSM Modems.
Movicon supports all  standard compliant GSM modem types.  Progea can provide very rugged, cost efficient and reliable industrial GSM modems to those who need them.



"We have chosen Progea as a technological and global partner for our
visualization solutions. The software technology developed by Progea has proved to be so innovative
and flexible that it perfectly supports our philosophy of IT-powered Automation."

Volker Bibelhausen
Vice President - Head of Business Unit Automation Systems
Phoenix Contact GmbH & Co. KG

Reference.
A list of just some of the
Progea product users:

Machinaries, Packaging, Mechanical,

  • American National Can
  • Emmeti
  • Farcon Packaging
  • Gämmerler
  • Gima Packaging
  • Hygena
  • Italpresse
  • Idra Presse
  • Irce
  • Luxottica
  • Kosme
  • Marcegaglia
  • Minganti
  • Nebiolo Printech
  • Olivetti Tech Center
  • Pellegrini
  • Philip Morris
  • Pininfarina
  • Procomac
  • Promau
  • Rolls Royce Turbines
  • Koch Glitsch
  • Sponge Iron, India
  • SKF Industries
  • Tetra Pack

Wastewater Treatment,

  • Acsm
  • Acque Ingegneria
  • Aimag
  • Antalia Municipality
  • Istanbul City
  • Lyonnaise des Eaux
  • Madrid City
  • Meta
  • Hera

Automotive,

  • Railways, AeroSpace
  • Alenia Aerospace
  • AMS Satelite localization
  • Autostrade Spa
  • Landini Tractors
  • Ferrari
  • Fiat Avio
  • Fiat/Tofas, Turkey
  • Ford Motors
  • FS Ferrrovie dello Stato
  • Henniges Automotive
  • IVECO
  • Nissan Trucks
  • Sam Groupe Arche
  • Suzuki Power Train, India
  • Tata Cummins

Building Automation,

  • Aquileia Historical Cathedral
  • Ataturk Airport Istanbul
  • Bonnet Markets
  • Castello Sforzesco, Milano
  • Deutsche Bank, Milano
  • Elba International Hotel
  • Esercito Italiano, Sardegna
  • Intelcom - Telecom S.Marino
  • Interporto Bologna
  • Gewiss - Schupa
  • Palaghiaccio Torino 2006
  • Siemens A&D
  • Special Penitentiary
  • 'Tolmezzo'
  • Urmet Enginnering
  • Vaticano - Sala Paolo VI
  • Centro Commerciale
  • Leonardo, Roma
  • Centre commercial
  • St. Etienne
  • Geant Casino, France
  • Seitha groupe Suez, France
  • New Delhi metro, India

Chemical & PetrolChemical,

  • Airpoirt Malpensa 2000
  • Airport Rome Fiumicino
  • AGIP
  • Auma
  • Bachelite
  • Colorobbia
  • Dow Chemical
  • Enichem
  • ENI
  • Esso
  • Fassa Bortolo
  • Hardy Explorations
  • IPLC India
  • Onduline
  • Osram
  • PDV Coupet
  • Petrodar Operation Co
  • Quatar Refineries
  • Texaco
  • Sapio
  • SOL
  • Western Coal

Food & Beverage,

  • Barilla
  • Beretta Salumificio
  • Campari
  • Galbani
  • Gasser Speck
  • GEA Tuchenhagen
  • Granarolo
  • Inalca Carni
  • Nestlè - Perugina
  • Nestlè - Motta
  • Montana Carni
  • Müller Yogurt
  • Parmalat
  • Pasta Corticella
  • Perfetti Van Melle, India
  • Perrier France
  • Plasmon
  • Procomac
  • Sanson
  • Sasib Food
  • Tukas

Heating & Refrigeration,

  • Baron Termodinamica
  • Bofrost
  • Clivet
  • Carel
  • GEA Technofrigo Dall'Orto
  • Laterforni
  • Lainox
  • Orogel Frost
  • Uniflair

Logistic.

  • Airport Rome Fiumicino
  • Airport Milano
  • Malpensa 2000
  • Conveyors Group
  • AEM Municipality
  • AGSM Municipality
  • AMPS Municipality

Research,

  • ENEA
  • ENI Risorse
  • EURATOM - Joint Research
  • Center ISPRA
  • University 'La Sapienza' Rome

Partners,

  • ASEM Spa
  • Panasonic Electric Works Italia
  • Phoenix Contact GmbH
  • VIPA GmbH






I/O Drivers List

Movicon Products include a large I/O Drivers library, as listed below.
The table list if the drivers support Win32/Win64 and/or WinCE operating systems,if they support the automatic Tags importer from PLC or devices editor and if they require an activation code.


This list has been updated: May. 2010


Manufacturer Interface-Device Protocol Requirements Win 32 Win CE Import Tags License Code

3S CoDeSys

CoDeSys Runtime Ver. 2.3, Ver. 3.x

PLC Handler

Ethernet board, GwClient.dll in the client and Supervisor system, 3S dll for connecting to version 3 PLC
ABB AC31, AC410 Modbus
Allen Bradley PLC-5, SLC-500, MicroLogix, ControlLogix, CompactLogix and FlexLogix DF1serial protocol
Allen Bradley PLC-5, SLC-500, MicroLogix, ControlLogix, CompactLogix and FlexLogix EtherNEt/IP
Alstom Alstom RTU and PLC devices IEC870-5-101 and 104
Applicom PC1000, PC2000, PC4000 Applicom Communication Server
April A2000 / 5000 / 7000 / PB80 / 200/ 400 Modbus
Beckhoff Beckhoff TwinCat SoftPLC Beckhoff I/O TwinCat ADS ADS Software Library
B&R System 2000 PLCs INA2000 protocol B&R PVI libraries, standard Ethernet or serial cable
BacNet/IP Any standard device BacNet/IP BacNet/IP - Annex J Binary / Analog / Multistate - I/O and value
CANOPEN Hilscher Can Open Master Can Open, Master HilscherCIF Cards and SyCon Configurator.
CARLO GAVAZZI Dupline Modbus
COSTER  Coster Devices  CBus    •      •
DANFOSS Danfoss Control Unit DK3964R – RK512 AKC OLE Interface
DUEMMEGI Contatto MCP XT FXP Protocol SMART RS232/RS485 converters for multiple connection
ECHELON Any Lonworks compliant device LonWorks LNS Server
ELMO ElMo Devices - Ethernet and Serial CEI Protocol Specification 79/5 and 79/6
ELAP PC100-n, Nexus, Lynx ELAP PTP Protocol
ELAU Elau CNC control devices CoDeSys Runtime
(or also via Modbus)

ELKRON Digit Italia controllers Digit Italia Serial protocol
ELKRON MP110, MP120 Alarm Central MP Serial protocol RS-232 line, TTL/RS232 module
GANTNER Gantner devices Modbus RTU or TCP
GE FANUC PLC Series 90, Micro Series SNP-XSerial Serial communication co-processor CMM 311 for the 90-30 series or CMM 711 for the 90-70 series
GUARDALL PX and QX series Guardall PS002 serial protocol
HITACHI H-Series Hitachi Serial Protocol Dedicated 15 pins cable or Hitachi Comm-H module
HILSCHER MPI Simatic S7-300, S7-400, VIPA PLC Siemens S7-MPI HilscherMPI-PB Cards and SyCon Configurator.
HILSCHER MPI Simatic S7-300, S7-400, VIPA PLC Siemens S7-MPI HilscherNetLink RJ45 Ethernet cable and SyCon
HILSCHER NETX Simatic S7-300, S7-400, VIPA PLC Siemens S7-MPI HilscherNETcoreX MPI board and configurator
HILSCHER Profibus DP, any compatible slave device Profibus DP Master HilscherCIF Cards and SyCon Configurator.
HILSCHER CAN Open, any compatible slave device CAN Open Master HilscherCIF Cards and SyCon Configurator.
IBH Softec IBH SoftPLC
IEC 60870-5-104 Any RTU compliant, connected to a Controlling Station via TCP/IP networking. IEC 60870-5-104 over TCP/IP
IEC 60870-5-101 Any RTU compliant, connected to a Controlling Station via RS232 or RS485. IEC 60870-5-101 unbalanced serial
INTEREL >Intermod Devices >Modbus RTU/ASCII >
ISAGRAF >ISAgraf SoftPLC >ISAGraf Ethernet >
KONNEX / EIB Any Konnex/EIB devices Konnex, EIS 1 to 15 Falcon libraries, BCU device or EIBNet/IP router
JETTER JetterController JetlPCOM7 Ethernet
PHOENIX CONTACT I/O and devices over Interbus Interbus IBS PCI SC/I-T PCI board, Interbus cables, DDI library
LENZE LecomAB Lenze Serial Lecom A/B communication module, RS232 connection or RS485 serial bus or optical fibre connection
MAUELL Mauell RTUs and PLCs DK3964
MAUELL Mauell RTUs and PLCs IEC870-5-101 or 104
MITSUBISHI PLC MELSEC-A Series Ethernet TCP-IP Ethernet module A1SJ71E71N-T
MITSUBISHI PLC MELSEC-FX and MELSEC-FX2N PLCs and compatible PTP serial protocol RS232/422 converter or Mitsubishi PLC progr.cable
MITSUBISHI PLC MELSEC-FX3U Ethernet Ethernet module FX3u-ENET, FX Configurator-EN software
MITSUBISHI PLC MELSEC-Q Series Format 1 with checksum serial prot. QJ71C24 communication module
MITSUBISHI PLC MELSEC-Q Series Ethernet TCP-IP QJ71E71 Ethernet communication module
MODBUS RTU Any standard Modbus Slave device Modbus RTU/ASCII Master
MODBUS TCP-IP Any standard Modbus Ethernet device Modbus TCP-IP
MOELLER PLCs PS4-200, PS300 and PS400 series SUCOM serial protoc. RS232/485 converter
NOTIFIER Notifier Devices - Ethernet and Serial CEI Protocol Specification 79/5 and 79/6 Notifier AM2000, AM6000
CPU E-Net and ETH-C module

OMRON Omron SYSMAC PLCs Host Link Omron Serial cable
OMRON Omron SYSMAC PLCs FINS Serial Omron Serial cable
OMRON Omron SYSMAC PLCs FINS Ethernet Omron Serial cable •
OVA Dardo Plus Dardo Plus protocol RS232/RS485 converter
PANASONIC NAIS Matsushita PLCFP Series MEWTOCOL protocol - serial and Ethernet communication FPWIN GR/PRO programming software for PLC config.; FP-WEB Server or FP2 ET-LAN unit for Ethernet comm.
PROFIBUS DP Applicom Server Card, Hilscher CIF, Siemens CP5613 Profibus DP Master
PROFIBUS FMS Siemens CP5613 SAPI S7 SIMATIC Softnet
Rockwell Automation PLC-5, SLC-500, MicroLogix, ControlLogix, CompactLogix and FlexLogix DF1serial protocol
Rockwell Automation PLC-5, SLC-500, MicroLogix, ControlLogix, CompactLogix and FlexLogix EtherNEt/IP
SAIA All PCD series PLCs Saia S-Bus protocol (multi mode) RS232 cable for PGU mode; Ethernet LAN adapter or USB adapter or RS485 for S-BUS mode; Ethernet LAN adapter for ProfiS-BUS mode •
SAUTER Sauter PLCs supporting S5-3964-R DK3964R – RK512
SAUTER Sauter devices supporting BacNet BacNet/IP
SCHNEIDER ELECTRIC Telemecanique PLCs and Uni-Telway protocol compliant devices Uni-Telway Slave smart RS232/RS485 converter (Schneider programming cable integrated converter not supported)
SCHNEIDER ELECTRIC Modicon TSX and any standard Modbus Slave device Modbus RTU/ASCII Master
SCHNEIDER ELECTRIC Modicon TSX and any standard Modbus Slave device Modbus TCP-IP
Shared Memory Customizable Data exchange with active processes through shared memory area Open I/O data exchange Third part application must support access to shared memory files •
SIEMENS Simatic-S5 Plcs AS511 RS-232-TTY interface (Programming cable)
SIEMENS Simatic-S5 Plcs DK3964R (RK512) CP524/5 and RK512
SIEMENS Simatic-S7-200 S7-PPI PPI PC-Adapter or compatible serial cable
SIEMENS Simatic-S7-300 - 400 S7-MPI MPI PC-Adapter or compatible serial cable
SIEMENS Simatic-S7-200-300 - 400 S7-Ethernet TCP Ethernet TCP interface
SIEMENS All PLC S7 and CP Comm. Boards (CP5611, CP5613, CP5614) NET SAPI Siemens SAPI S7 Library (Softnet)
SNMP Any SNMP compliant device EthernetSNMP
VIPA VIPA PLCs System 100, 200, 300, Speed7; Siemens PLCs S7 300 and 400 series and compatible. S7-MPI Protocol VIPA Embedded MPI
VIPA VIPA System 200V, 300V, 300S S7-Ethernet TCP
VIPA Any Profibus DP Master controller Profibus DP Slave VIPA HMI devices with integrated PROFIBUS interface
WAGO Any RTU controller or remote I/O Modbus RTU and TCP


(c) Progea Srl - Changes can be submitted without prior notice.

INS SCANDINAVIA ApS - VAT no: 31856701 - e-mail - Phone: +45 702-702-32 - Havnegade 39, 1058 København K

Bookmark and Share
